Pins
Description
Signal
29 ILS Energize
Output
30
Glideslope +Flag
Output
31
Glideslope +Down/-Flag (Glideslope 2.5V Common)
Output
32 Glideslope +Up
Output
33
Parallel DME - 1MHz
Output
34
Com Monitor Audio LO
Output
35 VOR/ILS Arinc-429 In B
Input
36
VOR/ILS Arinc-429 In A
Input
37
Parallel DME - 800KHz
Output
38 Glideslope Superflag
Output
39
Parallel DME - 400KHz
Output
40
Parallel DME - 200KHz
Output
41 Aircraft GND -
42
Parallel DME - 100KHz
Output
43
Parallel DME - 50KHz
Output
44
Aircraft Power In (Only used for Superflag Outputs)
Input
Table 39 P1006 Pin Description
6.1.4 P1050 Additional I/O Connector
Please note: This connector is not available on the AeroNav 780/800.
Pins
Description
Signal
1
Reserved
Input
2
Reserved
Input
3 Spare Input 4
Input
4
Spare Input 3
Input
5
Spare Input 2
Input
6
Spare Input 1
Input
7
Reserved
-
8 Reserved
-
9
Terrain Not Available Annunciate
Output
10
Terrain Warning Annunciate
Output
11 Terrain Caution Annunciate
Output
12
Reserved
Output
13
Spare Annunciate 2
Output
14 Spare Annunciate 1
Output
15
Reserved
Output
16
Reserved
-
17-21 Ground
-
22-39
NO CONNECT
-
40
ARINC 453 RX+
Input
41 ARINC 453 RX -
Input
42
GPS ARINC-429 Out 2A
Output
