6. System Installation
The following section will describe interfacing the AeroNav XXX to various other avionics and aircraft
equipment.
6.1 Pin Function List
The following Section Lists the Pin function for each connector.
6.1.1 P1001 Main Connector
1 VLOC Annunciate Output
2 GPS Annunciate Output
3 Waypoint Annunciate Output
4 Terminal Annunciate Output
5 Approach Annunciate Output
6 Message Annunciate Output
7 OBS Annunciate Output
8 Weight on Wheels (WOW) Output Output
9 Integrity Annunciate Output
10 Annunciate D Output
11 Annunciate E Output
12 Reserved Output
13 GPS Select Output
14 ILS/GPS Annunciate (Approach) Output
15 Aircraft Power 2 Input
16 Time Mark Out Output
17 Main Lateral Superflag Output
18 Main Vertical Superflag Output
19 Aircraft Power 1 Input
20 Aircraft Power 1 Input
21 Main +Left Output
22 Main +Right (1.65V COM) Output
23 Main Lat +Flag Output
24 Main Lat -Flag (GND) -
25 Main +To (1.65V Common) Output
26 Main +From Output
27 Main +Up (1.65V Common) Output
