6.1.9.4 ARINC 743A Output
Label Number Parameter Name
076
MSL Altitude
103
Track Angle
110
Latitude
111
Longitude
112
Ground Speed
120
Latitude, Fine
121
Longitude, Fine
125
Greenwich Mean Time
130
HIL
133
VIL
136
VFOM
140
UTC Time of Fix Fine
150
UTC Time of Fix From GPS
165
Vertical Velocity
166
North-South Velocity
174
East-West Velocity
203
Pressure Altitude
247
Horizontal Figure of Merit (HFOM)
260
Date
273
Operational Mode ,Number of Satellites Tracked
370
WGS-84 Altitude
377
Equipment Hex ID Code
6.1.10 ARINC 453
Description Connector Pin Signal Type
ARINC 453 RX + P1050 40 Input
ARINC 453 RX - P1050 41 Input
Table 53 ARINC 453 Input
6.1.11 RS170 Video
Description
Connector
Pin
Signal Type
RS170 Video In High P1050 77 Input
RS170 Video In Low P1050 78 Input
Table 54 RS170 Video Input
