89000046-014 KSN 780/8XX/900 AeroNav AML STC Installation Manual for Helicopters
Rev 0 Page 6-16
© Honeywell International Inc. Do not copy without express permission of Honeywell.
6.1.14.1 Serial/Parallel Tuning
NAV PAR DME – 8MHz P1006 14 Output
SER DME – CHAN REQ/PAR DME – 4MHz P1006 20 Output*
SER DME – RNAV MODE/PAR DME – 2MHz P1006 21 Output*
NAV PAR DME – 1MHz P1006 33 Output
NAV PAR DME – 800 kHz P1006 37 Output
NAV PAR DME – 400 kHz P1006 39 Output
NAV PAR DME – 200 kHz P1006 40 Output
NAV PAR DME – 100 kHz P1006 42 Output
NAV PAR DME – 50 kHz P1006 43 Output
NAV DME COMMON P1006 22 Input
Table 63 DME Serial/Parallel Output
* Used for 2x5 parallel DME tuning.
NAV DME Common must be pulled low for the AeroNav XXX to channel the DME. DME is
active if the voltage to ground is <1.9 V or the resistance to ground is <375 Ω.
Outputs is not more than 1.0V while sinking 20 mA.
6.1.14.2 King Serial DME Tuning
NAV Serial DME – DATA P1006 19 Output
NAV Serial DME – Clock P1006 18 Output*
Serial DME – CHAN REQ/PAR DME – 4MHz P1006 20 Output*
Serial DME – RNAV Mode/PAR DME – 2MHz P1006 21 Output
NAV DME Common P1006 22 Output
Table 64 DME Serial Tuning
Output high is >8V when driving a 360Ω and < 10mV for a low.
NAV DME Common must be pulled low for the AeroNav XXX to channel the DME. DME is active if the
voltage to ground is <1.9 V or the resistance to ground is <375 Ω.
6.2 Bezel Lighting
The AeroNav XXX can be connected to any of the following avionics lighting sources: 5/14/28VDC or 5
VAC. Dimming controls are described in Section 7.5.6.
