BENDIXKing KSN 8 Series - P1006 Navigation Connector

89000046-014 KSN 780/8XX/900 AeroNav AML STC Installation Manual for Helicopters
Rev 0 Page 6-4
© Honeywell International Inc. Do not copy without express permission of Honeywell.
Pins
Description
Signal Type
17 Intercom Microphone Audio LO
Input
18
COM Microphone Audio LO
Input
19
COM Audio LO
Output
20 Reserved
-
21
Aircraft GND
-
22
Aircraft GND
-
23 Synchro Y
Input
24
Synchro Z
Input
25
Synchro Reference Signal -
Input
Table 38 P1002 Pin Description
6.1.3 P1006 Navigation Connector
Note: This connector is not used in the AeroNav 880/905/780.
Pins
Description
Signal
1 VOR/LOC +To
Output
2
VOR/LOC +From (VOR/LOC 2.5V Common)
Output
3
VOR/LOC +Flag
Output
4 VOR/LOC -Flag (VOR/LOC 2.5V Common)
Output
5
VOR/LOC +Left
Output
6
VOR/LOC +Right (VOR/LOC 2.5V Common)
Output
7 Com Monitor Audio HI Output
8
VOR/LOC Composite Out
Output
9
VOR OBS Rotor C
Output
10 VOR OBS Rotor H (GND)
-
11
VOR OBS Stator E/G (VOR/LOC 2.5V Common)
Output
12
VOR OBS Stator F
Input
13
VOR OBS Stator D
Input
14
Parallel DME - 8MHz
Output
15 VOR/LOC Superflag
Output
16
VOR/ILS Audio HI
Output
17
VOR/ILS Audio LO
Output
18 Serial DME - Clock
Output
19
Serial DME - Data
Output
20
Ser DME-Chan REQ/PAR DME - 4MHz
Input/output
21 Ser DME-RNAV Mode/PAR DME - 2MHz
Input/output
22
DME Common
Input
23
VOR/ILS Arinc-429 Out B
Output
24 VOR/ILS Arinc-429 Out A
Output
25
VOR OBI Clock
Output
26
VOR OBI Sync
Output
27 VOR OBI Data
Output
28
VLOC Remote Transfer
Input
