BENDIXKing KSN 8 Series - Serial Data; Arinc 429

89000046-014 KSN 780/8XX/900 AeroNav AML STC Installation Manual for Helicopters
Rev 0 Page 6-10
© Honeywell International Inc. Do not copy without express permission of Honeywell.
6.1.8 Serial Data
6.1.8.1 RS-232
Description
Connector
Pin
Signal Type
RS-232 Output 1
P1001 56 Output
RS-232 Input 1
P1001 57 Input
RS-232 Output 2
P1001 58 Output
RS-232 Input 2
P1001 59 Input
RS-232 Output 3
P1001 41 Output
RS-232 Input 3
P1001 42 Input
RS-232 Output 4
P1001 54 Output
RS-232 Input 4
P1001 55 Input
RS-232 Output 5
‡
P1050 60 Output
RS-232 Input 5
‡
P1050 61 Input
RS-232 Output 6
‡
P1050 62 Output
RS-232 Input 6
‡
P1050 63 Input
Table 51 RS-232 Input / Output
‡
AeroNav 880/900 Only
6.1.9 ARINC 429
Description
Connector
Pin
Signal Type
GPS ARINC 429 OUT A
P1001 46 Output
GPS ARINC 429 OUT B
P1001 47 Output
GPS ARINC 429 IN 1 A
P1001 48 Input
GPS ARINC 429 IN 1 B
P1001 49 Input
GPS ARINC 429 IN 2 A
P1001 50 Input
GPS ARINC 429 IN 2 B
P1001 51 Input
VOR/ILS ARINC 429 OUT A *
P1006 24 Output
VOR/ILS ARINC 429 OUT B *
P1006 23 Output
VOR/ILS ARINC 429 IN A *
P1006 36 Input
VOR/ILS ARINC 429 IN B *
P1006 35 Input
GPS ARINC 429 OUT A‡
P1050 42 Output
GPS ARINC 429 OUT B‡
P1050 43 Output
Table 52 ARINC 429 Input / Output
‡ AeroNav 880/900 only, * N/A for AeroNav 880/780
