89000046-014 KSN 780/8XX/900 AeroNav AML STC Installation Manual for Helicopters
Rev 0 Page 6-9
© Honeywell International Inc. Do not copy without express permission of Honeywell.
6.1.7.6 Annunciators Electrical Output
VLOC Annunciate P1001 1 Output
GPS Annunciate P1001 2 Output
Waypoint Annunciate P1001 3 Output
Terminal Annunciate P1001 4 Output
Approach Annunciate P1001 5 Output
Message Annunciate P1001 6 Output
OBS Annunciate P1001 7 Output
Integrity Annunciate P1001 9 Output
LNAV GPS Select P1001 13 Output
ILS/GPS Approach P1001 14 Output
Table 48 Annunciator Output
All outputs sink up to 500 mA when activated.
6.1.7.7 Switch Inputs
OBS Mode Select P1001 71 Input
CDI Source Select P1001 73 Input
Table 49 Switch Inputs
The inputs are considered active if voltage to ground <1.9V or resistance to ground <375 Ω. These
inputs are considered inactive if voltage to ground is 11-33 VDC.
6.1.7.8 Time Mark Out
Time Mark Out P1001 16 Output
Table 50 Time Mark Output
Outputs a 1ms ± 1µs wide pulse once every 1.0 Second ± 2 ms. Output sources 1 mA at >3.8 V and
sinking 1 mA at less than 0.4 V.
