7.5.14 Remote XPDR Configuration
This page will configure the Avidyne AXP322 Remote transponder. Reference the AXP322 installation
manual as needed. The transponder must be configured to operate.
Please note; it may take up to 3 minutes to update the transponder configuration
after changing a parameter below.
A dual AXP322 transponder installation will require that this function is performed
on both transponders
Selection Description
Hex Code Enter the aircraft's Mode S Address issued by the registration authority.
This code must be entered as a hexadecimal value.
A/C Width Enter the aircraft's width in meters
A/C Length Enter the aircraft's length in meters
GPS Lin. Offset Enter the distance from the front of the aircraft to the GPS antenna in
meters
1090 MHz Receiver Enter "Yes" if the aircraft is equipped with 1090 MHz ADS-B In receiver
UAT Receiver Enter "Yes" if the aircraft is equipped with UAT ADS-B In receiver
Squat Input For ADS-B out compliance, a squat switch is required for automatically
selecting the transponder air or ground mode of operation. For aircraft
without a squat switch, connect the squat switch input of the
transponder to P1001 pin 8 of one of the AeroNav XXX for AeroNav’s
with software 10.0.0 or higher. In either case, set the transponder to
“Avidyne” when performing the squat switch setup.
A/C Class Enter the aircraft category
A/C Speed Enter the aircraft speed
GPS Lat. Offset Enter the lateral distance in meters for the GPS antenna
Certification VFR installations, aircraft with a non-WAAS antenna (reference Section
7.5.11), or unapproved ADS-B out installations must set this field to
"uncertified". All other installations reference the Avidyne AXP322
installation manual for certification level.
Table 114 Remote XPDR Configuration Selections
7.5.15 WiFi Setup
If the AeroNav is equipped with the optional Wi-Fi and Bluetooth options, configuration of these
interfaces may be desired.
7.5.15.1 Wi-Fi Configuration
The AeroNav Wi-Fi system can be configured in one of two ways. The AeroNav may operate as a Wi-
Fi access point (WAP) or can connect to an external access point provided by another accessible
device.
NOTE: The AeroNav Maintenance mode refers to a WAP configuration as "Local". Similarly,
Maintenance mode refers to a configuration in which the AeroNav connects to a separate access
point as "Remote".
