89000046-014 KSN 780/8XX/900 AeroNav AML STC Installation Manual for Helicopters
Rev 0 Page 1-2
© Honeywell International Inc. Do not copy without express permission of Honeywell.
1.4.2 AeroNav 780/800 Specifications
The AeroNav 780/800 unit has the following characteristics:
1.4.2.1 AeroNav 780/800 Physical and Electrical Specifications
Physical Specifications
Bezel Height 2.66 inches (67 mm)
Bezel Width 6.25 inches (159 mm)
Depth (w/Connectors) 11.00 inches (279 mm)
Weight Table 12 AeroNav Installed Weights
Connectors (Aircraft Mating Connector) P1001 - 78-position High Density D-Subminiature
(male)
P1002- 25-position Standard D- Subminiature
(female)
P1006- 44-position High Density D- Subminiature
(male)
Electrical Requirements
Voltage 9-33 VDC
Current AeroNav 780:
4.4A main at 14VDC
3.0A main at 28VDC
AeroNav 800:
4.4A main, 6.5A COM, 0.5A NAV at 14VDC
3.0A main, 1.0A NAV at 28VDC
3.6A @ 10W, 4.1A @ 16W COM at 28VDC
Dimming Bus 28VDC/14VDC/5VDC/5VAC
Cooling Requirements Not Required
Operating Limits Reference Appendix A: Environmental
Qualification Form
Table 11 AeroNav 780/800 Specifications
1.4.2.2 AeroNav 780/800 Installed Unit Weight in Pounds
Backshells (Less Wiring)
Installed Weight with Backshells
(Less Wiring)
4.00 5.48 5.72
800
5.16 6.88 7.46
Table 12 AeroNav Installed Weights
