Appendix A: Environmental Qualification Form
AeroNav 900, AeroNav 880, AeroNav 800, AeroNav 780
Environmental Tests
RTCA/DO-160G
Section
Test Category
Temperature and Altitude
4.0
Low Temp
4.5.2
Equipment qualified to Category C1
High Temp
4.5.3 & 4.5.4
Equipment qualified to Category C1
In-Flight Loss of Cooling
4.5.5
Equipment qualified to Category W
Altitude 4.6.1 Equipment qualified to Category C1
Decompression
4.6.2
Equipment qualified to +55,000 Ft.
Overpressure 4.6.3 Equipment qualified to -15,000 Ft.
Temperature Variation
5
Equipment qualified to Category B
Humidity
6
Equipment qualified to Category A
Operational Shocks & Crash Safety
7
Equipment qualified to Category E
Vibration
‡
8
Equipment qualified to Category S, Curves B
and M, Category U, Curve G
Explosive Atmosphere 9 Category X, no test performed
Waterproofness
10
Category X, no test performed
Fluids Susceptibility
11
Category X, no test performed
Sand and Dust 12 Category X, no test performed
Fungus Resistance
13
Category X, no test performed
Salt Spray
14
Category X, no test performed
Magnetic Effects 15 Equipment qualified to Class Z
Power Input
16
Equipment qualified to Category B
Voltage Spike
17
Equipment qualified to Category A
Audio Frequency Conducted Susceptibility
18
Equipment qualified to Category B
Induced Signal Susceptibility
19
Equipment qualified to Category ZC
Radio Frequency Susceptibility 20
Equipment qualified to Category W
(conducted)/WR (radiated)
Emission of Radio Frequency Energy 21 Equipment qualified to Category M
Lightning Induced Transient Susceptibility
22
Category B4HZL4 (Power) and B3K4L4 (All
other I/O)
Lightning Direct Effects 23 Category X, no test performed
Icing 24 Category X, no test performed
Electrostatic Discharge
25
Equipment qualified to Category A
Fire and Flammability
26
Category X, no test performed
‡
BendixKing requires the following for helicopter installations:
Plug & Play Installations – Installer has option to use existing tray;
New Installations – Installer must use BendixKing's Helicopter Tray, reference Table 26 or Table 27;
Table 118 Environmental Qualification Form – AeroNav 900/880/800/780
