6.5 Datalink Weather
The AeroNav XXX can be connected to Datalink Weather Systems via RS232. The AeroNav XXX
supports the following Datalink Weather Systems:
Manufacturer
Model
Data
Format
Notes
Avidyne Corporation
MLB700 RS232
SkyTrax100(formerly MLB100)
[Navworx 200-0011-()-()]
RS232 AeroNav with s/w
10.1.0 or later
Skytrax 100B RS232 AeroNav with s/w
10.1.0 or later
Freeflight Systems
FDL-978-RX RS232 AeroNav with s/w
10.1.0 or later
Heads-up
Technologies
XMD-076 RS232 AeroNav with s/w
10.2.3.1 or later
Garmin
GDL69/69A
P/N 011-00986-00 or 011-00987-00
only Pre Software 10.2.3.1 With
Software 10.2.3.1 or later P/N 011-
03177-X0 will also work
RS232 Garmin Software
version 4.01 or
later For first
generation GDL’s
Garmin
GDL 88 RS232
WSI
AV300
AV350
RS232
Table 67 Weather Datalink
6.6 Audio Panels
The AeroNav XXX can be connected to various Audio Panels via standard analog connections. For
audio panels not listed below, the installer must verify compatibility. The AeroNav XXX supports the
following Audio Panels:
Manufacturer
Model
Data
Format
Notes
Avidyne
AMX240 Analog
Audio
Garmin
SL10/ SL10MS/ SL10M/ SL10S/ SL15/
SL15M/ GMA340/ GMA347
Analog
Audio
Honeywell
(Bendix/King)
KMA24/ KMA24H-70/71 KMA26/
KMA28
Analog
Audio
PS Engineering
PMA6000/ PMA 7000 Series/ PMA
8000 Series
Analog
Audio
Table 68 Audio Panels
