6.7 GAD 42
The AeroNav XXX can be connected to the Garmin GAD42 Interface Adapter.
If the AeroNav XXX is replacing a GNS530/W or GNS430/W that had previously been connected to a
GAD42, then no action is required since the configuration is already saved in the GAD42.
If this is a new installation of an AeroNav XXX (i.e. not replacing an existing GNS-530/W or GNS-
430/W) or if the GAD42 had to be replaced for service, then the GAD42 must be configured via a
manual strapping method as described in Garmin P/N 190-00159-00 GAD42 Installation Manual,
Section 5.1.
6.8 Air Data System Sources
The AeroNav XXX can be connected to either Uncorrected or Baro-corrected Altitude Sources. The
AeroNav XXX can be connected to the following Air Data Systems:
Manufacturer
Model
Data Format
Notes
Aspen EFD1000 ARINC 429 Low Speed
Avidyne Entegra PFD ARINC 429 Low Speed
Garmin G500/600 ARINC 429 Low Speed
B & D 90004-003 ARINC 429 Low Speed
Honeywell (Bendix/King) KDC281/481 ARINC 429 Low Speed
Insight TAS 1000 RS232
Table 69 Air Data Systems
6.8.1.1 Uncorrected Pressure Altitude Sources
The AeroNav XXX can accept uncorrected altitude from multiple sources in the following formats:
ARINC 429, RS232, or a Gray Code altitude encoder. If multiple altitude sources are connected, the
AeroNav XXX will use the altitude sources in this order (highest first):
1. ARINC 429 ADC
2. ARINC 429 EFIS
3. ARINC 429 Traffic Advisory System
4. RS232 FADC
5. RS-232 Altitude Encoder
6. Parallel Altitude Encoder (Gray Code)
6.8.1.2 Baro-corrected Altitude Sources
The AeroNav XXX can accept baro-corrected altitude from multiple sources. The AeroNav XXX can
accept Altitude information from altitude Air Data Systems in the following formats: ARINC 429 or
RS232. If multiple altitude sources are connected to the AeroNav XXX, the AeroNav XXX will use the
altitude sources in this order (highest first):
1. ARINC 429 INS/IRU
2. ARINC 429 EFIS
3. ARINC from Transponder
4. RS232 FADC
