89000046-014 KSN 780/8XX/900 AeroNav AML STC Installation Manual for Helicopters
Rev 0 Page 6-3
© Honeywell International Inc. Do not copy without express permission of Honeywell.
Pin
Description
Signal Type
62 Altitude C2 Input
63 Altitude C1 Input
64 Altitude B4 Input
65 Altitude B2 Input
66 Altitude B1 Input
67 Altitude A4 Input
68 Altitude A2 Input
69 Altitude A1 Input
70 Altitude D4 / Weight on Wheels (WOW) Input Input
71 OBS Mode Select Input
72 Aircraft Power 2 Input
73 CDI Source Select Input
74 COM Remote Recall Forward Input
75 COM Remote Recall Reverse Input
76 LTG BUS 2 HI Input
77 Aircraft GND -
78 Aircraft GND -
Table 37 P1001 Pin Description
6.1.2 P1002 Communication Connector
Note: This connector is not used in the AeroNav 880/780.
Pins
Description
Signal Type
1
Reserved
-
2
Ethernet 1 TX+
Output
3
Ethernet 1 TX-
Output
4
COM Microphone Key
Input
5 Intercom Microphone Audio HI
Input
6
COM Microphone Audio HI
Input
7
COM Audio HI
Output
8 Ethernet 1 RX+
Input
9
Ethernet 1 RX-
Input
10
Synchro X
Input
11 Aircraft Power Input
12
Aircraft Power
Input
13
Synchro Reference Signal +
Input
14 Transmit Interlock (Unused)
Input
15
COM Remote Transfer
Input
16
Reserved
-
