89000046-014 KSN 780/8XX/900 AeroNav AML STC Installation Manual for Helicopters
Rev 0 Page 6-12
© Honeywell International Inc. Do not copy without express permission of Honeywell.
Label Number Parameter Name 1 2 3 4 5 6 7
326
Lateral Scale Factor
•
•
•
•
•
•
327
Vertical Scale Factor
•
•
•
•
•
330
Conic Arc Inbound Course
•
•
331
Conic Arc Radius
•
•
332
Conic Arc Course Change Angle
•
•
333
Airport Runway Azimuth
•
•
334
Airport Runway Length
•
•
335
Holding Pattern Azimuth
•
•
340
Procedure Turn Azimuth
•
•
351
Distance to Destination
•
•
•
•
•
•
352
Estimated Time to Destination
•
•
•
•
•
•
371
Specific Equipment ID
•
•
•
•
•
•
377
Equipment Hex ID Code
•
•
•
•
•
•
•
6.1.9.2 VHF ARINC Output
Applies To: AeroNav 800, 900 Only
6.1.9.3 Onboard Radar ARINC Output
When configured, an RDR-2000 channel shall transmit the following data:
Label Number Parameter Name
270 Radar Mode, Tilt, and Gain
271 Roll-Trim, Range
273 Vertical Profile
275 Display Mode
324 Pitch angle (Degrees), If Stabilization Enabled
325 Roll Angle (Degrees), If Stabilization is Enabled
Label Number Parameter Name
034G
VOR/ILS Frequency
035G
DME Frequency
100G
Selected Course # 1
173
Localizer Deviation
174
Glideslope Deviation
222
VOR Omni bearing
371G
Specific Equipment
377
Equipment Hex ID Code
