89000046-014 KSN 780/8XX/900 AeroNav AML STC Installation Manual for Helicopters
Rev 0 Page F-3
© Honeywell International Inc. Do not copy without express permission of Honeywell.
ADF
Air Data
IRU/INS
Other
Other
Other
GNS-530/W or GNS-430/W Maintenance Mode Entry:
GNS-530 configuration data is accessed from the GNS-530/W Maintenance Mode settings which is entered via holding ENTR button
on 530/W bezel during power application.
GNS-530/W or GNS-430/W Page Navigation:
Use the inner right knob on the GNS-530/W to scroll through the maintenance mode pages. Each clockwise click of the knob selects
the next page. On pages where selectable fields exist, a push of the right knob will produce a flashing cursor. The outer right knob
moves through the fields on a page when there is a flashing cursor. Twist the inner right knob clockwise to see a list of choices. Use
the inner right knob to scroll through the list of choices and press the “ENT” button to select the desired choice.
AeroNav XXX Maintenance Mode Entry:
AeroNav XXX configuration data is accessed via Mx Mode which is entered by starting the AeroNav with a USB Fob already installed
or selecting the AUX page, SYS tab, ensuring that the “Select” LSK = Software, and then pressing the “Download Logs” LSK, followed
by the “Confirm” LSK. These tables contain all the data that can be entered at time of installation to ensure the AeroNav XXX is
properly configured. There are additional setup options that selectable by the pilot (Display Options on AUX Setup tab) that are not
documented here.
AeroNav XXX Page Navigation:
To reach the AeroNav pages on which this data is to be entered, select the CONFIG tab in Maintenance Mode. Use the outer right
knob to select the page – each clockwise click of the outer right knob selects the next page in the list. Push the right knob in to
generate a cursor and then use the outer right knob to select an individual field with the cursor. Then twist the inner right knob to
scroll through the selectable options for that field and push in the right knob when done with each field selection.
For retrofit installations (those installations in which an AeroNav XXX is replacing a GNS-530/W or GNS-430/W), enter the data in the
following tables/menu pages from the corresponding fields recorded below in the GNS-530/W or GNS-430/W tables on the left side
of each page. Repeat for each retrofit AeroNav XXX.
For new installations (those installations in which an AeroNav 880/900 is NOT replacing a GNS-530/W or GNS-430/W), select and
record the appropriate settings for each configuration page per the descriptive material below each table.
