3. Make sure the Host is properly connected to a power source.
4. Press Start pairing to pair the Host to the Button via the web management interface, you
will have two minutes to pair with the Button.
5. Press the split screen key on the side of the Button for five seconds. The LED indicator
of the Button will blink blue for about 10 seconds. The pairing process is ongoing. A
“Pairing in progress” message will be shown on the screen.
00:00:00
00:00:05
6. The LED indicator of the Button will turn static green when the Host and Button are
successfully paired.
• Images are for reference only. Each product features a different serial number.
• The maximum number of Buttons you can pair with one Host is 32.
