4. With the frame aligned, press the frame toward the driver until the
three (3) spring loaded locking clamps snap into place. It may be
helpful to grasp the back of the driver and close your grip to push
the cap into place as pictured.
Removing a Hoop
To remove a hooped cap from the installed Red Wide Angle Driver, use the
following steps.
1. Press the three locking clamps on the driver while gently pulling
back on the frame.
2. This will allow the frame to release and be pulled free from the
driver.
