Loading/Removing a Hoop with the Wide Angle Driver
Loading a Hoop
To load a hooped cap onto the installed wide angle driver, use the following
steps.
1. Rotate the hooped cap so the bill 90° to allow the bill to pass un-
der the needle case.
2. Rotate the bill back up so that it is behind the needle case and the
location tab on the driver aligns with the notch in the frame.
3. This also aligns the rectangular holes along the edge of the frame
with the spring loaded locking clamps on the driver.
