6 of 109
3. Make sure the machine power switch is in the OFF position. Plug
the power cable into the inlet.
If you are using a line conditioner, as recommended, plug the other
end of the cable into the dedicated line conditioner.
4. Connect the line conditioner into a power source.
Connecting the Network Cable (Single Machine)
For a single machine to computer connection, a crossover cable is required.
(You can also use 2 Ethernet cables and an Ethernet switch).
1. Connect one end of the crossover cable into the Ethernet jack on
the machine.
2. Connect the other end of the crossover cable into the Ethernet jack
on the computer. The location of this network connection will vary
from computer to computer. If using multiple network cards, it may
be helpful to label them on the back of the computer.
3. Move on to Selecting the Connection.
