59 of 109
Removing the Hoop Support Arms
1. Use a 6mm hex wrench to loosen each of the two thumb screws
attaching each arm to the x-carriage.
2. Using your ngers, fully loosen the thumb screws.
3. Remove the support arms from the x-carriage.
Adjusting the Spring Clips
When you have a hoop installed, you should make sure both spring clips
are attached securely to the arms. If either side of the hoop can move front
to back underneath the clip, the clip needs to be adjusted. It may be nec-
essary to move the hoop forward for easier access to the nuts holding the
clips. To adjust the clip:
1. Use a 5mm Hex nut driver to loosen the two nuts holding the clip
in place.
2. Push the block underneath the clip as far forward as it will go.
3. Hold the block in place while tightening the nuts.
