BEUMER stretch hood® S
Technical data
BA-6090103-EN
19.08.09
17
2 Technical data
Requirements on the place of installation
Designation Data
Installation height < 1,000 m
Ambient temperature 0 °C to +40 °C
Building
For a trouble-free operation of the system, the following conditions have to be
fulfilled:
• minimum ambient temperature -5 °C
• max. wind velocity 15 m/min.
Foundation
The foundation must be designed as monolithic foundation without expansion
joints. The permissible tolerance in the evenness of the surface is +/- 7.5 mm.
Mounting holes for straddling dowels with a diameter of 21 mm and a depth of
150 mm must be possible. When using compound anchors, mounting holes with
a diameter of 32 mm and a depth of 250 mm must be possible. The quality of
concrete must be at least BN 1045 according to DIN 25
Lighting
Arrange for sufficient lighting around the machine. Avoid glaring light, strobo-
scopic effects, reflections, flashing or other harmful influences.
Power supply
Electrical energy
Designation Data
Rated voltage for the system 3/N/PE AC 460 V 60 Hz
Rated voltage for the control DC 24 V
Rated voltage for the emergency stop circuit DC 24 V
Rated voltage for emergency stop contactors AC 115 V
Rated voltage for motor contactors DC 24 V
Rated voltage for valves DC 24 V
Permissible voltage fluctuation ± 10 %
For a safe and trouble-free operation, a stable power supply has to be provided.
