Beumer stretch hood S - Torque List

BEUMER stretch hood® S
Installation
BA-6090103-EN
19.08.09
35
Torque list
Galvanised screws Black, untreated screws
Tightening torque (Nm) Tightening torque (Nm)
d 5.6 8.8 10.9 12.9 5.6 8.8 10.9 12.9
M 6 4,5 9,5 13 16 4,8 10 14 17
M 8 11 23 32 39 12 25 35 41
M 10 22 46 64 77 23 49 69 83
M 12 38 80 110 135 40 86 120 145
M 14 60 125 180 215 64 135 190 230
M 16 92 195 275 330 98 210 295 355
M 20 180 385 540 650 190 410 580 690
M 24 305 660 930 1100 330 710 1000 1200
M 30 620 1350 1850 2250 660 1450 2000 2400
M 36 1050 2300 3200 3850 1150 2450 3450 4150
M 42 1700 3650 5150 6200 1850 3950 5550 6650
M 48 2600 5550 7800 9350 2800 5950 8400 10100
Observe the indicated tightening torque for screw and bolt connections!
Use only torque wrenches for this kind of connections!
