BEUMER stretch hood® S
Technical data
BA-6090103-EN
19.08.09
19
Film specification
The film used must correspond to the film specification. Only then a perfect func-
tioning of the system can be ensured.
The following changes require that a film roll is ordered first as sample for a
functional test:
• Change of film manufacturer or supplier
• Change of film dimensions
• Change of film thickness
If the test has been successful, larger quantities of film can be ordered.
The current film specification is indicated on the specification sheet included in
the annex.
Performance data
Designation Data
BEUMER stretch hood
®
6090103.50 - 130
Packaging capacity 40 packages/h
Maximum package length 1,219 mm
Maximum package width 1,016 mm
Maximum package height 2,750 mm
Height of platform 4,500 mm
Max. weight of full pallet 2,000 kg
Installed power approx. 6.7 kW
Field of application, ambient temperature +5 °C to +40 °C
Noise emission < 70 dB(A)
Pallet transport system
6090103.10 - 40
6090103.160 - 190
Height of transport system 700 mm
Maximum bearing capacity per roller conveyor 2,000 kg
Conveying speed, transport system 0.23 m/s
Installed power approx. 5.6 kW
Field of application, ambient temperature +5 °C to +40 °C
Noise emission < 75 dB(A)
