Technical data
BEUMER stretch hood® S
18 BA-6090103-EN
19.08.09
Pneumatic energy
Designation Data
Compressed-air connection required 6 bar
Permissible input pressure max. 10 bar
Compressed-air connection R 3/8 "
Air volume required per package 180 NL
In order to achieve a safe and trouble-free operation, a stable compressed-air
supply system has to be provided. The compressed air used should be filtered
and dried; it should be oil-free and have an input pressure of 6 bar.
• Solid particles:
class 4; max. permissible particle size 40 my.
• Water content:
class 4; dew point +10 °C = 9.356 g/m³ water content.
• Oil content:
class 4; max. permissible content 5 mg/m³.
Pneumatic cylinders are provided with a basic lubrication in the workshop.
Therefore, the cylinders can be used with either oiled compressed air (0.5 to 5
drops of oil / 1000 litres of air) or oil-free compressed air.
Once used with oiled compressed air, the cylinders should always be used with
oiled compressed air (oil content > 10 mg/m³, about 5 drops of oil / 1000 litres o
air). Oiled compressed air eliminates the basic lubrication.
Material/items transported
Designation Data
Product medical products
Product packing cardboard boxes
Items transported palletised load units
Weight max. 2,000 kg
Temperature max. 80 °C
Pallets
The pallets must correspond to the dimensions indicated in the installation draw-
ing. The tolerances for length, width and height may amount to ± 3 mm.
All boards of the lower and upper side must be in place and in perfect condition.
Any edges, nails etc. protruding must be removed beforehand. Only then the
pallets can be transported properly.
