Beumer stretch hood S - Pallet Roller Conveyor

BEUMER stretch hood® S
Technical description
BA-6090103-EN
19.08.09
29
Pallet roller conveyor
1 Idlers
2 Support
3 Drive unit
The pallet roller conveyor transports and stores pallets. Length and width of the
pallet roller conveyor, roller pitch, drive power and conveying speed are adapted
to the particular application. The idlers with welded-on chain sprocket disks are
driven by staggered chains. The chain drive is covered with a protective hood.
