BL-CB33-0115 - 03-01-2018 12-27
COMPARTMENT
Pos. Part Number Description
Qty.
Reqd.
Notes
1 0000-000433-00 SCREW, M8 X 12 5
2 2130-190002-00 MIDDLE COVER 1
3 0000-000649-00 SCREW, M8 X 20 5
4 2130-190001-00 UPPER COVER 1
Used up to serial num-
ber 326110893
5 2130-172000-00 HINGE BLOCK L 1
6 2130-182000-00 HINGE BLOCK R 1
7 2333-131000-00 COVER ASSEMBLY L 1
8 2333-141000-00 COVER ASSEMBLY R 1
Used up to serial num-
ber 326110893
8a 2333-141000-0A COVER ASSEMBLY R 1
Used from serial num-
ber 326110894
9 1220-150005-00 NUT, M8 2
10 0000-000109-00 SCREW, M8 X 16 8
11 0000-000159-00 WASHER, LOCK, M8 11
12 0000-000194-00 WASHER, FLAT, M8 11
13 2125-600005-00 BUFFER BLOCK 1
14 2214-150002-00 WASHER 5
15 2333-130001-00 MOUNTING PLATE 2
16 1146-151002-30 MANUAL HOLDER 1
Used from serial num-
ber 326110894
17 0000-000119-00 SCREW M5x12 4
18 0000-000546-00 NUT M5 4
To Next Page
