Big Joe CB33 - Elevation System (Three Stage Mast)

BL-CB33-0115 - 03-01-2018 12-39
ELEVATION SYSTEM (THREE STAGE MAST)
Pos. Part Number Description
Qty.
Reqd.
Notes
1 2333-610000-30-01 OUTER MAST 1
Used up to serial number
324190319 For Lift Height 157”
1a 2333-610000-3A-01 OUTER MAST 1
Used from serial number
324190320 For Lift Height 157”
1b 2333-610000-50-01 OUTER MAST 1
Used for Lift Height 157” When
Side Shift
2 0000-000285-00 BOLT, M12 X 35 1
3 0000-000060-00 WASHER, LOCK, M12 6
4 0000-000283-00 BOLT, M10 X 35 4
5 0000-000063-00 WASHER, LOCK, M10 6
6 2125-612000-00 ROLLER ASSEMBLY 8
7 2125-600007-30 BRACKET 1
8 2125-600001-30 ROLLER BRACKET 1
9 2333-420000-30-01 CYLINDER, FREE LIFT 1 For Lift Height 157”
10 0000-000244-00 BOLT, M10 X 30 2
11 — LIFT CARRIAGE 2 See Lift Carriage Section
12 0000-000071-00 WASHER, FLAT, M10 6
13 0000-000183-00 RETAINER RING, M35 4
14 2214-600001-00 CHAIR ROLLER 4
15 2125-620000-30-01 MIDDLE MAST 1 For Lift Height 157”
15a 2333-620000-40-01 MIDDLE MAST 1
For Lift Height 157” - When Side
Shift
16 0000-000613-00 BOLT, M12 X 50 2
17 0000-000222-00 WASHER, FLAT, M12 2
18 2125-600002-30 HOSE ROLLER 1
19 2125-600003-00 BUSHING 1
20 2333-630000-30-01 INNER MAST 1 For Lift Height 157”
20a 2333-630000-40-01 INNER MAST 1
For Lift Height 157” -When Side
Shift
