Big Joe CB33 - Free Lift Cylinder (Three Stage Mast)

BL-CB33-0115 - 03-01-2018 12-71
FREE LIFT CYLINDER (Three Stage Mast)
Pos. Part Number Description
Qty.
Reqd.
Notes
— 2333-420000-30-01 FREE LIFT CYLINDER 1
Used for Lift Height 157”,
Three Stage Mast
— 2333-ZZG-3A SEAL KIT 1 Includes 1,2,7
1 0000-000045-00 RING, WIPER, 35 X 43 X 5-6.5 1
2 0000-000690-00 O-RING, 60 X 3.1 1
3 2130-420002-30 GLAND NUT 1
4 2130-420001-30-01 PISTON ROD 1
Used for Lift Height 157”,
Three Stage Mast
5 2130-420003-30 RING, BACK UP, 70 x 65 x 20 1
6 0000-000698-00 SNAP RING, 53 x 63 x 2 1
7 0000-000699-00 ROD PACKING, 53 X 63 X 6 1
8 2333-421000-30-01 CYLINDER TUBE 1
Used for Lift Height 157”,
Three Stage Mast
