SECONDARY LIFT CYLINDER (Three Stage Mast)
Pos. Part Number Description
Qty.
Reqd.
Notes
— 2130-410000-30-01 SECONDARY LIFT CYLINDER 1
Used for Lift Height 157”,
Three Stage Mast
— 2130-2BG SEAL KIT 1 Includes 1,2,3
1 0000-000084-00 RING, WIPER, 35 X 43 X 5-6.5 1
2 0000-000370-00 O-RING, 40 X 3.1 1
3 1220-420001-0A GLAND NUT 1
4 2130-410001-30-01 PISTON ROD 1
Used for Lift Height 157”,
Three Stage Mast
5 2130-410003-30 COLLAR 1
6 2130-410004-30 RING, BACK UP 1
7 2130-410002-30 PISTON 1
8 0000-000132-00 ROD PACKING, 30 X 40 X 6 1
9 2130-411000-30-01 CYLINDER TUBE 1
Used for Lift Height 157”,
Three Stage Mast
10 2125-410006-30 PIN 1
