BL-CB33-0115 - 03-01-2018 12-13
DRIVE ASSEMBLY - Used up to serial # S2410419
Pos. Part Number Description
Qty.
Reqd.
Notes
— 2333-200000-10 DRIVE ASSEMBLY 1
1 2333-240000-10 DRIVE MOTOR 1
2 2333-210000-00 BRAKE ASSEMBLY 1
3 2333-200002-10 BEARING 1
4 2333-200003-10 GEAR 1
5 2333-220000-10 TRANSMISSION 1
6 2333-230000-10 DRIVE WHEEL 1
7 0000-000869-00 BOLT, M8 X 40 12
8 0000-000154-00 SCREW, M8 X 35 6
9 0000-000159-00 WASHER, LOCK, M8 6
10 0000-000176-00 WASHER, FLAT, M8 6
11 0000-000516-00 SCREW, M12 X 40 6
12 0000-000060-00 WASHER, LOCK, M12 6
13 0000-000373-00 WASHER, FLAT, M12 6
14 0000-001268-10 WASHER, LOCK, M14 5
15 0000-001269-10 NUT, M14 X 1.5 5
16 2333-270000-10 STEERING MOTOR 1
17 2333-200004-00 GEAR 1
18 0000-000321-00 SCREW, M8 X 20 4
19 0000-000386-00 SCREW, M6 X 20 1
20 0000-000056-00 WASHER, LOCK, M6 1
21 2333-200001-10 WASHER 1
22 2333-210001-10 BRAKE LINING 1
23 0000-001287-10 SCREW, M6 X 70 3
