BL-CB33-0115 - 03-01-2018 12-75
TILT CYLINDER - USED UP TO SERIAL NUMBER 324170306
Pos. Part Number Description
Qty.
Reqd.
Notes
— 2333-440000-00 TILT CYLINDER 1
— 2320-QXG-0A SEAL KIT 1 Includes 7,8,9,10
1 2333-440001-00 CLEVIS 1
2 0000-001012-00 BEARING 1
3 0000-000849-00 SEAL, M47 1
4 0000-001013-00 BOLT, M14 X 55 1
5 0000-000233-00 WASHER, LOCK, M14 1
6 0000-001014-00 NUT, M14 1
7 0000-001017-00 DUST SEAL, LYO 30 X 47 X 10 1
8 0000-001016-00 SEAL, 30 X 43 X 7 1
9 2320-440001-00 GUIDE RING 1
10 0000-000967-00 0-RING, 80 X 3.1 1
11 2320-442000-00 PISTON ROD 1
12 0000-001015-00 SEAL, YX70 X 80 X 6 2
13 2320-440003-00 WEAR RING, 20 X 2.5 1
14 2333-441000-00 CYLINDER BODY 1
15 3218-810007-00 BUSHING 1
16 0000-000588-00 GREASE FITTING 1
