CHAIN ASSEMBLY
Pos. Part Number Description
Qty.
Reqd.
Notes
1 2125-640001-00 ADJUSTING BOLT 1
2 0000-000187-00 NUT, M16 X 1.5 3
3 0000-000188-00 COTTER PIN, M3.2 X 20 2
4 2125-640002-00 PIN 2
5 2125-640000-00-02
CHAIN I
(MOUNTS TO FREE LIFT CYL)
1
Used for Lift Height 104”,
Telescopic Mast
5a 2125-640000-00-04
CHAIN I
(MOUNTS TO FREE LIFT CYL)
1
Used for Lift Height 126”,
Telescopic Mast
5b 2125-651000-30-01
CHAIN I
(MOUNTS TO FREE LIFT CYL)
1
Used for Lift Height 157”,
Three Stage Mast
5c 2125-652000-30-01
CHAIN II
(MOUNTS TO INNER MAST)
1
Used for Lift Height 157”,
Three Stage Mast
6 2125-640003-00 CHAIN ANCHOR 1
7 0000-000686-00 COTTER PIN, M3.2 X 32 1
8 0000-000176-00 WASHER, FLAT, M8 2
