Big Joe CB33 - Lift Carriage (Three Stage Mast)

BL-CB33-0115 - 03-01-2018 12-47
LIFT CARRIAGE (Three Stage Mast)
Pos. Part Number Description
Qty.
Reqd.
Notes
1 0000-000221-00 BOLT, M12 X 30 4
2 0000-000060-00 WASHER, LOCK, M12 4
3 0000-000373-00 WASHER, FLAT, M12 4
4 2320-631000-00 BACKREST 1
5 2125-641000-30 LIFT CARRIAGE 1
Used up to serial num-
ber 324200418
5a 2125-641000-3A LIFT CARRIAGE 1
Used from serial num-
ber 324200419
6 2125-630001-00 FORK 2
6a 2333-630001-50 FORK 2 When Side Shift option
7 2125-630001-10 PIN ASSEMBLY 2
8 2125-612000-00 ROLLER ASSEMBLY 4
9 0000-000030-00 SCREW, M10 X 16 1
10 2125-642000-30 PLATE 1
Used between serial
number 324170307 and
324200418
11 0000-000109-00 SCREW M8×16 2
Used between serial
number 324170307 and
324200418
12 0000-000159-00 LOCKWASHER Ø8 2
Used between serial
number 324170307 and
324200418
13 0000-000176-00 FLATWASHER Ø8 2
Used between serial
number 324170307 and
324200418
14 2130-641000-40 SIDE SHIFT ASSEMBLY 1 When Side Shift option
