Big Joe CB33 - Elevation System (Three Stage Mast)

BL-CB33-0115 - 03-01-2018 12-41
ELEVATION SYSTEM (THREE STAGE MAST) - CONTINUED
Pos. Part Number Description
Qty.
Reqd.
Notes
21 2130-410000-30-01 CYLINDER, SECONDARY LIFT 2 For Lift Height 157”
22 2214-600005-00 SHIM A.R. As Required
23 2125-600006-30 CYLINDER BRACKET 2
24 2125-600005-30 CLIP 2
25 2214-600007-00 CUSHION BLOCK 2
26 0000-000109-00 SCREW, M8 X 16 4
27 0000-000159-00 WASHER, LOCK, M8 4
28 0000-000176-00 WASHER, FLAT, M8 4
29 0000-000004-00 SCREW, M5 X 12 8
30 0000-000206-00 WASHER, LOCK, M5 8
31 0000-000390-00 WASHER, FLAT, M5 8
32 2125-500001-3A SENSOR BRACKET 1
Used up to serial number
324170306
32a 2333-500001-30 SENSOR BRACKET 1
Used from serial number
324170307
33 2125-500003-00 PROXIMITY SWITCH 1
34 2130-520003-0A PROXIMITY SWITCH HARNESS 1
35 2125-500002-3A SENSOR BRACKET 1
36 2125-500002-00 PROXIMITY SWITCH 1 For Lift Height 157”
37 2125-520009-22 PROXIMITY SWITCH HARNESS 1 For Lift Height 157”
38 0000-000919-00 Bolt M12×65 1
When Side Shift
39 K25S100007-Y Double Tube Round 1
40 3215-800002-30 Tube Axle 1
41 3215-800001-30 Plate 1
42 3215-800004-30 Fixed Plate 1
43 3215-800005-30 Bracket 1
44 3215-800006-30 Middle Tube Round 1
45 3215-800003-30 Tube Axle 1
46 0000-000242-00 Bolt M8×16 3
