Big Joe CB33 - Lift System (Three Stage Mast)

BL-CB33-0115 - 03-01-2018 12-65
LIFT SYSTEM (Three Stage Mast - Not with Side Shift)
Pos. Part Number Description
Qty.
Reqd.
Notes
1 0000-000069-00 SEAL, M16 8
2 2706-161600-00 CONNECTOR, M16 x 1.5 x M16 x 1.5 2
3 2130-430000-30 TUBE ASEMBLY 2
4 2125-400002-30 MANIFOLD 1
Used up to serial number
324190319
4a 2333-430001-30 MANIFOLD 1
Used from serial number
324190320
5 2701-161600-00 CONECTOR, M16 X 1.5 X M16 X 1.5 2
6 0000-000169-00 SCREW, M8 X 30 2
7 2702-142000-00 CONNECTOR, G1/4 X M20 X 1.5 1
Used up to serial number
324190319
7a 2701-202000-00 CONNECTOR M20×1.5-M20×1.5 1
Used from serial number
324190320
8 0000-000044-00 SEAL, M14 1
Used up to serial number
324190319
8a 0000-000510-00 SEAL, M20 1
Used from serial number
324190320
9 2125-430000-3B TUBE ASSEMBLY 1
Used up to serial number
324190319
9a 2333-431000-30 TUBE ASSEMBLY 1
Used from serial number
324190320
10 2125-450000-3A TUBE ASSEMBLY 1
Used up to serial number
324190319
10a 2333-432000-30 TUBE ASSEMBLY 1
Used from serial number
324190320
11 2706-162000-10 CONNECTOR, M16 X 1.5 X M20 X 1.5 1
12 2125-440000-3A-01 HOSE 1
Used up to serial number
324190319
12a 2333-433000-30-01 HOSE 1
Used from serial number
324190320
13 0000-000109-00 SCREW M8×16 3
14 0000-000159-00 LOCKWASHER Ø8 3
15 0000-000176-00 FLATWASHER Ø8 3
