BL-CB33-0115 - 03-01-2018 12-53
HYDRAULIC SYSTEM - USED UP TO SERIAL NUMBER 324190319 (NOT WITH SIDE SHIFT)
Pos. Part Number Description
Qty.
Reqd.
Notes
1 0000-000155-00 SCREW, M10 X 40 2
2 0000-000063-00 WASHER, LOCK, M10 2
3 0000-000007-00 WASHER, FLAT, M10 6
4 2112-410004-00 WASHER 4
5 2333-460000-10 PUMP AND MOTOR ASSEMBLY 1
6 2333-411000-00 RESERVOIR 1
7 0000-000056-00 WASHER, LOCK, M6 4
8 0000-000620-00 BOLT, M6 X 16 4
9 2125-420001-00 MAGNET 1
10 0000-000635-00 PLUG, M18 X 1.5 1
11 0000-000510-00 WASHER, M20 1
12 2130-423000-00 FILTER 1
13 2333-420000-00 HOSE 2
14 2333-430000-00 HOSE 2
15 3218-711000-00 HOSE, TILT 2
16 3218-710500-00 MANIFOLD 1
17 2702-141600-00 CONNECTOR, G1/4-M16 X 1.5 2
18 0000-000044-00 SEAL, M14 6
19 0000-000322-00 SCRREW, M8 X 25 2
20 0000-000159-00 WASHER, LOCK, M8 2
21 2707-141400-00 CONNECTOR, G1/4-M14 X 1.5 1
22 2402-143500-00 BOLT, G1/4 X 35 1
23 2333-450000-00 HOSE 1
24 2402-143700-00 BOLT, G1/4 X 37 1
