Big Joe CB33 - Elevation System (Telescopic)

BL-CB33-0115 - 03-01-2018 12-35
ELEVATION SYSTEM (TELESCOPIC)
Pos. Part Number Description
Qty.
Reqd.
Notes
1 2125-612000-00 ROLLER ASSEMBLY 4
2 2214-600001-00 CHAIN ROLLER 2
3 0000-000244-00 BOLT, M10 X 30 2
4 0000-000071-00 WASHER, FLAT, M10 6
5 0000-000109-00 SCREW, M8 X 16 4
6 0000-000159-00 WASHER, LOCK, M8 4
7 0000-000176-00 WASHER, FLAT, M8 4
8 0000-000285-00 BOLT, M12 X 35 2
9 0000-000060-00 WASHER, LOCK, M12 2
10 0000-000283-00 BOLT, M10 X 35 4
11 0000-000063-00 WASHER, LOCK, M10 6
12 2214-600005-00 SHIM A.R. As Required
13 2214-600004-0A CYLINDER BRACKET 2
14 2214-600003-0A CLINDER CLIP 2
15 2130-410000-00-01 CYLINDER 2
Used for Lift Height
104”
15a 2130-410000-00-02 CYLINDER 2
Used for Lift Height
126”
16 2333-620000-00-01 INNER MAST 1
Used for Lift Height
104”
16a 2333-620000-20-01 INNER MAST 1
Used for Lift Height
104” When Side Shift
16b 2333-620000-00-03 INNER MAST 1
Used for Lift Height
126”
16c 2333-620000-20-03 INNER MAST 1
Used for Lift Height
126” When Side Shift
