Big Joe CB33 - Elevation System (Telescopic)

BL-CB33-0115 - 03-01-2018 12-37
ELEVATION SYSTEM (TELESCOPIC) - CONTINUED
Pos. Part Number Description
Qty.
Reqd.
Notes
17 2333-610000-00-01 OUTER MAST 1
Used up to serial num-
ber 324190319 - for Lift
Height 104”
17a 2333-610000-0A-01 OUTER MAST 1
Used from serial num-
ber 324190320 - for Lift
Height 104”
17b 2333-610000-00-03 OUTER MAST 1
Used up to serial num-
ber 324190319 - for Lift
Height 126”
17c 2333-610000-0A-03 OUTER MAST 1
Used from serial num-
ber 324190320 - for Lift
Height 126”
17d 2333-610000-20-01 OUTER MAST 1
Used for Lift Height
104” When Side Shift
17de 2333-610000-20-03 OUTER MAST 1
Used for Lift Height
126” When Side Shift
18 — LIFT CARRIAGE 2
See Lift Carriage Sec-
tion
19 2214-600007-00 CUSHION BLOCK II 2
20 2130-500002-0A SENSOR BRACKET 1
21 2130-500001-0A SENSOR BRACKET 1
22 2125-520009-26 PROXIMITY SWITCH HARNESS 1
Used for Lift Height
104”
22a 2125-520009-29 PROXIMITY SWITCH HARNESS
Used for Lift Height
126”
23 2130-520003-0A PROXIMITY SWITCH HARNESS 1
24 0000-000004-00 SCREW, M5 X 12 8
25 2125-500003-00 PROXIMITY SWITCH 8108 2
26 0000-000390-00 WASHER, FLAT, M5 8
27 0000-000206-00 WASHER, LOCK, M5 8
28 0000-000632-00 BOLT M12×80 1
Used when Side Shift
29 0000-000222-00 FLATWASHER Ø12 1
30 2125-600002-30 OIL PIPE ROLLER 2
31 2125-600003-00 BUSHING 2
