BL-CB33-0115 - 03-01-2018 12-59
TILT SYSTEM
Pos. Part Number Description
Qty.
Reqd.
Notes
1 0000-000255-00 BOLT, M8 X 20 2
2 0000-000159-00 WASHER, LOCK, M8 4
3 0000-000176-00 WASHER, FLAT, M8 4
4 2333-400001-00 SHAFT 2
5 2333-440000-00 TILT CYLINDER 2
Used up to Serial Num-
ber 324170306
5a 2333-440000-0A TILT CYLINDER 2
Used from Serial Num-
ber 324170307
6 0000-000321-00 SCREW, M8 X 20 2
7 3218-840000-00 SHAFT 2
To Next Page
