Big Joe CB33 - Frame

BL-CB33-0115 - 03-01-2018 12-29
FRAME
Pos. Part Number Description
Qty.
Reqd.
Notes
1 2333-100002-00 COVER 1
2 2333-120000-00 BATTERY COVER 1
3 2333-100001-10 CABLE BAFFLE 1
4 2333-150000-00 COUNTER WEIGHT L 1
5 2333-160000-00 COUNTER WEIGHT R 1
6 0000-000368-00 SCREW, M8 X 12 4
7 2214-150002-00 WASHER 4
8 0000-000242-00 BOLT, M8 X 16 1
9 0000-000159-00 WASHER, LOCK, M8 10
10 0000-000176-00 WASHER, FLAT, M8 10
11 0000-000026-00 SCREW, M8 X 30 2
12 0000-000015-00 SCREW, M6 X 10 1
13 0000-000056-00 WASHER, LOCK, M6 1
14 0000-000380-00 WASHER, FLAT, M6 1
15 0000-000087-00 SCREW, M12 X 25 4
16 0000-000060-00 WASHER, LOCK, M12 4
17 0000-000373-00 WASHER, FLAT, M12 4
18 2333-110000-10 FRAME 1
Used up to serial #
S2410419
18a 2333-110000-1A FRAME
Used from serial #
S2410420
19 1280-161000-00 ROLLER FRAME 1
20 1280-160001-00 ROLLER 4
21 0000-000322-00 SCREW, M8 X 25 6
22 1280-180002-00 BAFFLE 1
Used up to serial #
S2410158
22a 2333-180001-00 BAFFLE 1
Used from serial #
S2410159
