BL-CB33-0115 - 03-01-2018 12-83
Pos. Part Number Description
Qty.
Reqd.
Notes
1 0000-000321-00 SCREW, M8 X 20 4
2 0000-000159-00 WASHER, LOCK, M8 4
3 0000-000194-00 WASHER, FLAT, M8 4
4 — ELECTRICAL PANEL 1
See Electrical Panel
Section
5 1220-520002-1C KEY SWITCH 1
5a 1120-500016-10 KEYS 1 Set of 2 Keys
6 1115-510006-20 HOUR METER 1
With Hour meter. Set
the BDI dial to the fol-
lowing: M = Industrial
Battery, Q = Maint.Free
Battery
7 1220-520007-0D METER WIRING HARNESS 1
8 0000-000170-00 SCREW, M6 X 30 2
9 0000-000056-00 WASHER, LOCK, M6 3
10 2333-531000-00 BATTERY CONNECTOR 1
11 1120-112008-00 SPACER 1
12 1120-500003-00 HORN 1
13 0000-000121-00 SCREW, M4 X 35 4
14 0000-000122-00 WASHER, LOCK, M4 4
15 0000-000702-00 WASHER, FLAT, M4 4
16 1220-520010-0C FAN 1
17 1220-500004-00 FAN GUARD 1
18 3712-405000-00 ALARM BUZZER 1 Optional
19 0000-000433-00 SCREW M8×12 1 Optional
To Next Page
