LIFT SYSTEM (TELESCOPIC - WITH SIDE SHIFT)
Pos. Part Number Description
Qty.
Reqd.
Notes
1 0000-000069-00 Washer ø16 6
2 2706-161600-00 Connector M16×1.5-M16×1.5 2
3 2130-470000-00 Metallic Pipe Assembly 2
4 2333-430001-30 Block Cross 1
5 2712-201300-00 Plug M20×1.5 1
6 0000-000169-00 Screw M8×30 2
7 2701-161600-00 Connector M16×1.5-M16×1.5 2
8 0000-000510-00 Washer ø20 1
9 0000-000044-00 Washer ø14 4
10 3218-724000-00 Metal Tube 1
11 2333-432000-20-01 Oil Pipe 1 Used with Lift Height 104”
11a 2333-432000-20-03 Oil Pipe 1 Used with Lift Height 126”
12 3215-860300-10 Connector M14×1.5-M14×1.5 2
13 2130-450000-10 Oil Pipe 2
14 2706-141400-00 Connector M14×1.5-M14×1.5 2
15 0000-000109-00 Screw M8×16 2
16 0000-000159-00 Lockwasher ø8 2
17 0000-000176-00 Flatwasher ø8 2
