LIFT SYSTEM (Three Stage Mast - With Side Shift)
Pos. Part Number Description
Qty.
Reqd.
Notes
1 0000-000069-00 WASHER Ø16 8
2 2706-161600-00 CONNECTOR M16×1.5-M16×1.5 2
3 2130-430000-30 METALLIC PIPE ASSEMBLY 2
4 2333-430001-30 BLOCK CROSS 1
5 2701-161600-00 CONNECTOR M16×1.5-M16×1.5 2
6 0000-000169-00 SCREW M8×30 2
7 2701-202000-00 CONNECTOR M20×1.5-M20×1.5 1
8 0000-000510-00 WASHER Ø20 1
9 2333-431000-30 METALLIC OIL PIPE ASSEMBLY 1
10 2333-432000-30 METALLIC OIL PIPE ASSEMBLY 1
11 2706-162000-10 CONNECTOR M16×1.5-M20×1.5 1
12 2333-433000-30-01 HOSE 1
13 0000-000109-00 SCREW M8×16 3
14 0000-000159-00 LOCKWASHER Ø8 3
15 0000-000176-00 FLATWASHER Ø8 3
16 3215-860100-30 FOUR WAY VALVE 1
17 2130-440000-40-01 OIL PIPE 2
18 3215-860200-30 METAL TUBE 1
19 2333-431000-40-01 OIL PIPE 2
20 3215-860500-30 METAL TUBE 1
21 0000-000044-00 WASHER Ø14 2
22 2130-430000-40 OIL PIPE 2
23 2701-141400-00 CONNECTOR M14×1.5-M14×1.5 1
To Next Page
