DRIVE ASSEMBLY - Used from serial # 325130601
Pos. Part Number Description
Qty.
Reqd.
Notes
1 1280-210048-00 MOTOR 1
2 1280-210000-00 BRAKE ASSEMBLY 1
3 0000-000516-00 SCREW M12×40 6
4 0000-000060-00 LOCKWASHER Ø12 6
5 0000-000373-00 FLATWASHER Ø12 6
6 1280-520009-10 SWITCH WIRE HARNESSII 1
7 0000-000006-00 SCREW M6×30 1
8 1280-210053-10 ELASTIC COLLAR 1
9 0000-000322-00 SCREW M8×25 3
10 0000-000159-00 LOCKWASHER Ø8 7
11 CK10-240000-20 STEERING MOTOR 1
12 1280-210042-10 MOTOR GEAR 1
13 2415-220000-1A GEAR CASE ASSEMBLY 1
Used between serial #
325130601 and
326140869
13a ZK18-240000-A0-02 GEAR CASE ASSEMBLY 1
Used from serial #
326140870
14 2415-230000-1A DRIVE WHEEL 1
15 0000-001131-10 NUT M12×1.5 6
16 0000-000025-00 LOCKWASHER Ø12 6
17 0000-001281-00 SCREW M8×75 4
18 0000-000176-00 FLATWASHER Ø8 4
19 CK10-240001-20 KB-SENSOR,STEERING MOTOR 1
20 1120-240014-3A STUDS 6
21 0000-001287-10 SCREW M6x70 3
22 2333-210004-00 BRAKE LINING 1
