BL-CB33-0115 - 03-01-2018 12-19
GEAR CASE ASSEMBLY - Used between serial # S2410420 and 326140869
Pos. Part Number Description
Qty.
Reqd.
Notes
-- 2415-220000-10 GEAR CASE ASSEMBLY 1
Used between serial number
S2410420 and 325130600 -
Includes pos. # 1-35
-- 2415-220000-1A GEAR CASE ASSEMBLY 1
Used between serial number
325130601 and 326140869 -
Includes pos. # 1-35
1 2415-220001-10 GEAR CASE 1
2 2415-220002-10 COVER 1
3 2415-220008-10 O-RING 1
4 0000-000056-00 LOCKWASHER Ø6 8
5 0000-000055-00 SCREW M6×16 8
6 2415-GB10-00 SPIRAL BEVEL GEAR KIT 1 Includes 2 gears
7 1120-240007-30 WASHER 1
8 1120-240008-30 LOCKING PLATE 1
9 0000-000277-00 BOLT M8×25 3
10 0000-001054-00 BEARING 2
11 2415-220009-10 COVER 2
12 0000-000077-00 SCREW M6×12 14
13 2415-GB10-10 GEAR KIT 1 Includes 2 gears
14 0000-000379-00 FLATWASHER Ø14 1
15 0000-001055-00 WASHER Ø14 1
16 0000-001056-00 NUT M14×1.5 1
17 2415-220014-10 SEAL WASHER 1
18 2415-220003-10 OUTPUT SHAFT 1
Used between serial #
S2410420 and 325130600
18a 2415-220003-1A OUTPUT SHAFT 1 Used from serial # 325130601
19 2415-220018-10 COVER PLATE 1
20 2415-220010-10 SEAT 1
21 0000-001285-10 BEARING 2
