BL-CB33-0115 - 03-01-2018 12-21
GEAR CASE ASSEMBLY - Used between serial # S2410420 and 326140869 - Continued
Pos. Part Number Description
Qty.
Reqd.
Notes
22 2415-220012-10 PLATE 1
23 0000-000255-00 BOLT M8×20 6
24 0000-001699-00 SNAP RING ø55 1
25 2415-220015-10 SEAL WASHER 1
26 0000-000762-00 ELASTIC COLLAR Ø62 1
27 0000-000183-00 RETAINER RING Ø35 1
28 0000-001282-10 BEARING 2
29 2415-220011-10 SLEEVE 1
30 2415-220013-10 GEAR 1
31 0000-000321-00 SCREW M8×20 8
32 0000-001286-10 BEARING 1
33 0000-001283-10 BEARING 1
34 2415-220016-10 RING WIPER VL-160 1
35 2415-220017-10 DUST COVER 1
