Figure 4: Ultra-low temperature freezer UF V 700, open
(A) Outer door
(B) Door lock and controller housing (description chap. 2.2)
(C) Door handle
(D) Compressor housing
(E) Air filter flap (checking and cleaning / replacing the filter chap. 24.4.1)
(F) Castors (front castors lockable by breaks)
(G) Compartment with variable shelf
(H) Compartment door
(
