Binder UF V - Door Lock and Controller Housing

UF V (E3) 03/2019 Page 19/116
2.2 Door lock and controller housing
The controller operator panel is integrated in the freezer‘s door lock and controller housing (B).
With the standard chamber a door handle (C) serves to open and close the chamber door.
Front view Left chamber side
Figure 5: Standard chamber: Door lock and controller housing with controller operator panel and door
handle
Chambers with the “Door access system “option are equipped with an electromechanical door locking and
electronic access control via NumPad.
Front view Left chamber side
Figure 6: Chamber with “Door access system” option: Door lock and controller housing with Numpad,
controller operator panel and pushbutton “OPEN” to open the door
(B)
(C) (C)
(B)
