UF V (E3) 03/2019 Page 68/116
15.2.5 Setting the standard gateway
Access to this function is possible only if manual IP address assignment has been selected (chap. 15.2.1)
Path: Normal display Settings Ethernet Standard
gateway
Press the OK button to enable the setting.
The standard gateway entry is done in four steps, corresponding to the number sections: (1).(2).(3).(4)
Principle of entry:
• Use the OK button to select the desired section of the standard gateway 1/4, 2/4, 3/4, 4/4 in the upper
display line
• Use the Arrow buttons to enter the value for the selected section of the standard gateway
• For details please refer to the description of the similar procedure in chap. 15.2.3 “Assigning the IP
address”.
With the arrow-down button you can now change to the assign the DNS server address.
With the Back button you can go back to the “Ethernet” submenu and, repeatedly pressing it, to Normal
display.
15.2.6 Assigning the DNS server address
Access to this function is possible if manual IP address assignment (chap. 15.2.1) or manual DNS server
address assignment (chap. 15.2.2) has been selected.
With manual IP address assignment:
Path: Normal display Settings Ethernet DNS server
address
With manual DNS server address assignment:
Path: Normal display Settings Ethernet DNS server
address
Press the OK button to enable the setting.
The DNS server address entry is done in four steps, corresponding to the number sections: (1).(2).(3).(4)
Principle of entry:
• Use the OK button to select the desired section of the DNS server address 1/4, 2/4, 3/4, 4/4 in the
upper display line
• Use the Arrow buttons to enter the value for the selected section of the DNS server address
• For details please refer to the description of the similar procedure in chap. 15.2.3 “Assigning the IP
address”.
With the Back button you can go back to the “Ethernet” submenu and, repeatedly pressing it, to Normal
display.
