2.1 Chamber overview
(A)
(B)
(C)
(D)
(E)
(F)
(A)
(B)
(D)
(E)
(F)
Standard equipment
Optional equipment:
“Door access system”
Figure 3: Ultra-low temperature freezer UF V (example UF V 700), front view
(A) Outer door
(B) Door lock and controller housing (description chap. 2.2)
(C) Door handle
(D) Compressor housing
(E) Air filter flap (checking and cleaning / replacing the filter chap. 24.4.1)
(F) Castors (front castors lockable by breaks)
